| 設(shè)備型號 | 加工寬度范圍 (mm) |
雙邊磨削量 (mm) |
選型產(chǎn)量參考 (m²/24h) |
對角線誤差 |
磨頭功率 |
總裝機功率 (kW) |
耗氣量 |
單臺機外形尺寸 |
總 重 |
||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 前臺機 | 后臺機 | ||||||||||
| 600 |
ENCBS600/40+4 |
300-600 |
4-15 |
18000±10% |
≤ 0.5 |
5.5 |
128.55/130.25 |
280 |
5980×2760×1850 |
7300 | 7500 |
| 600 |
ENCBS600/52+4 |
300-600 |
4-15 |
25000±10% |
≤ 0.5 |
5.5 |
162.75/164.45 |
280 |
6850×2760×1850 |
8300 | 8500 |
| 600 |
ENCBS600/60+4 |
300-600 |
4-15 |
30000±10% |
≤ 0.5 |
5.5 |
185.55/187.25 |
280 |
7430×2760×1850 |
9000 | 9200 |
| 1000 | ENCBS1000/40+4 | 300-1000 | 4-15 | 15000±10% | ≤ 0.6 | 5.5 | 128.55/130.25 | 280 | 5980×3160×1850 | 7700 | 7900 |
| 1000 | ENCBS1000/52+4 | 300-1000 | 4-15 | 18000±10% | ≤ 0.6 | 5.5 | 162.75/164.45 | 280 | 6850×3160×1850 | 8500 | 8700 |
| 1000 | ENCBS1000/60+4 | 300-1000 | 4-15 | 30000±10% | ≤ 0.6 | 5.5 | 185.55/187.25 | 280 | 7430×3160×1850 | 9200 | 9400 |
| 1200 | ENCBS1200/40+4 | 300-1200 | 4-15 | 18000±10% | ≤ 0.8 | 5.5 | 128.55/130.25 | 280 | 5980×3360×1850 | 7800 | 8000 |
| 1200 | ENCBS1200/52+4 | 300-1200 | 4-15 | 25000±10% | ≤ 0.8 | 5.5 | 162.75/164.45 | 280 | 6850×3360×1850 | 8600 | 8800 |
| 1200 | ENCBS1200/60+4 | 300-1200 | 4-15 | 30000±10% | ≤ 0.8 | 5.5 | 185.55/187.25 | 280 | 7430×3360×1850 | 9500 | 9700 |
| 設(shè)備型號 | 加工寬度范圍 (mm) |
雙邊磨削量 (mm) |
選型產(chǎn)量參考 (m²/24h) |
對角線誤差 |
磨頭功率 |
總裝機功率 (kW) |
耗氣量 |
單臺機外形尺寸 |
總 重 |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 吸水率 0.3-1% |
吸水率 1-3% |
吸水率 3-6% |
前臺機 | 后臺機 | |||||||||
| 600 |
ENCGBS600/40+4 |
300-600 |
4-8 |
9500±10% |
11000±10% | 13000±10% |
≤ 0.5 |
5.5 |
128.55/130.25 |
280 |
5980×2760×1850 |
7300 | 7500 |
| 600 |
ENCGBS600/52+4 |
300-600 |
4-8 |
11500±10% |
13000±10% | 15000±10% |
≤ 0.5 |
5.5 |
162.75/164.45 |
280 |
6850×2760×1850 |
8300 | 8500 |
| 600 |
ENCGBS600/60+4 |
300-600 |
4-8 |
13500±10% |
15000±10% | 17000±10% |
≤ 0.5 |
5.5 |
185.55/187.25 |
280 |
7430×2760×1850 |
9000 | 9200 |
| 1000 | ENCGBS1000/40+4 | 300-1000 | 4-8 | 13000±10% | 16000±10% | 18000±10% | ≤ 0.6 | 5.5 | 128.55/130.25 | 280 | 5980×3160×1850 | 7700 | 7900 |
| 1000 | ENCGBS1000/52+4 | 300-1000 | 4-8 | 16000±10% | 18000±10% | 21000±10% | ≤ 0.6 | 5.5 | 162.75/164.45 | 280 | 6850×3160×1850 | 8500 | 8700 |
| 1000 | ENCGBS1000/60+4 | 300-1000 | 4-8 | 18000±10% | 21000±10% | 23000±10% | ≤ 0.6 | 5.5 | 185.55/187.25 | 280 | 7430×3160×1850 | 9200 | 9400 |
| 1200 | ENCGBS1200/40+4 | 300-1200 | 4-8 | 10000±10% | 12000±10% | 14000±10% | ≤ 0.8 | 5.5 | 128.55/130.25 | 280 | 5980×3360×1850 | 7800 | 8000 |
| 1200 | ENCGBS1200/52+4 | 300-1200 | 4-8 | 12000±10% | 14000±10% | 16000±10% | ≤ 0.8 | 5.5 | 162.75/164.45 | 280 | 6850×3360×1850 | 8600 | 8800 |
| 1200 | ENCGBS1200/60+4 | 300-1200 | 4-8 | 14000±10% | 16000±10% | 18000±10% | ≤ 0.8 | 5.5 | 185.55/187.25 | 280 | 7430×3360×1850 | 9500 | 9700 |
